Broader and better applicability
Lead advantages in performance and price
Comprehensive bag emptying solutions
STAB-850 SMALL BAG SLITTER
STAB-850 Small Bag Slitter: This machine can handle almost all bags of different sizes, structures, and materials. For single-layer bags, minimal debris enters the material when the bag is cut open with a single blade. For pellet material, the average bag emptying rate is around 99.95% to 99.99%, and for powder material, the average bag emptying rate is around 99.8% to 99.95%.
Parameters for: STAB-850 standard unit
| Measures: | Width 1.25m * length 2.45m, height 2.24m |
| Energy consumption: | 2.2kwh/3.2KW; max150L/min/0.6mpa |
| Emptying rate/capacity: | About 99.8%-99.99% emptying rate with 100-150 bags/hour |
| Suitable for material: | Most powder, granule and pellets material |
| Suitable for bag: | Almost all kinds of bags and sacks |
| Weight: | Around 1.2 ton, use 3 ton forklift to move the machine |
| Bag specification: | Suitable for outer length 550-850mm, width 350-550mm, height 100-200mm range |
Equipment description
The working process of this automatic bag emptying machine: the belt conveyor sends the bag into inner part of the small bag slitter, then the internal bag catching device grab and carry the bag to other side of the machine, during the moving process, one piece of blade cut open the bag from the bottom, the material falls into the hopper by gravity, the bag emptying device imitating human movement to shake the bag to empty the material out of the bag thoroughly, in the end the empty bag to be automatically collected and extruded out by the empty bag compactor. This machine can explosion-proof configuration, stainless steel configuration or customized for different working conditions.
Simulating human movement to empty the bag
The machine is designed to simulate human movement to cut and empty the bags, which enable this machine capable of handle almost all different kinds of bags in different sizes with high emptying rate.
Can handle different bags by one machine
| Film-coated woven bag | Paper-plastic composite bag |
| Plastic bag | Paper bag |
| Ordinary Woven Bag | Tie closure bag |
| Vacuum bag | Foil bag |
| Single-layer bag | Multi-layer bag |
One piece of blade: This automatic small bag emptying machine use a piece of blade in the process of bag cutting under most case for single-layer bags, for multi-layer bags, one more blade can be added to improve the emptying rate.
Near 0 bag debris: Non-tied bags in the form of single-layer bag, including plastic bags, coated woven bags, using a piece of blade in the process of bag cutting, almost no bag debris generated.
If you are chemical enterprise like LIPON, ETERNIT, you have many different material in different sacks, which are in different size, different bag material, and different bag structure, but you need to empty these bags with one machine to dose each batch of the different materials, XUNLI small bag slitter is the best choice, there is no any other similar small machine can apply to some many differences.
